Pulse Filter Pleated dust Filter Dust Collector Filter Cartridge
Production description:
Filter Cartridge Product Descriptions:
ECOGRACE Gas Turbine Air Intake Filter cartridges are modern and reliable for air intake applications. They ensure high efficient filtration of dust and other contaminants even in the most polluted environments. Normally these are made of mixture of polyester & cellulose and Nanofiber filter media. The filter media have much better pleat ability & dimensional stability. Pleated filter media offer high filtration efficiency, very fine retention level, easy clean ability & aesthetically good product than other normal filter media.
The filter media is point bonded polyester with even fiber distribution which results in an even dirt load and increased water flow.
The Sharp & Uniform pleated media provides filtration area (square footage) that meets or exceeds the original manufacturers' specifications.
An open core design provides sturdy support for the media without restricting flow. Increased flow rates result in less wear on the pump and reduced energy usage.
Anti-microbial end caps inhibit the growth of bacteria, mold and mildew while supporting the core and media.
Banded Pleats maximize flow during operation, and help to reduce the frequency of cleaning. Banded pleats also make the cartridge easier to clean.
Industrial Dust Collection Cartridge Filter Features:
A:Compact design, reliable performance.
B:Low energy consumption, highest filter efficiency and low cost.
1.Top Cap
Open steel plate, no rust
2.End Cap:
Open or closed steel plate,no rust
3.Filter Surface:
Various available
4.Inner Core;
Galvanized mesh
5.Outer strip band:
Two pieces as reinforcement
6.Gasket:
Seamless neoprene foam
Filters surface-load particulate for easier pulse cleaning
Lower pressure drops (initially and life-long)
Superior releasing abilities reduce cleaning cycles
Reduced energy costs and compressed air savings
Cleaner Air (Lower Emissions)
Longer Filter Life (Fewer Cleanings/Stress)
Reduced Downtime (Fewer Filter Swaps)
Lower Disposal Costs (Fewer Filter Swaps)
Filter Cartridge Product Descriptions:
ECOGRACE Gas Turbine Air Intake Filter cartridges are modern and reliable for air intake applications. They ensure high efficient filtration of dust and other contaminants even in the most polluted environments. Normally these are made of mixture of polyester & cellulose and Nanofiber filter media. The filter media have much better pleat ability & dimensional stability. Pleated filter media offer high filtration efficiency, very fine retention level, easy clean ability & aesthetically good product than other normal filter media.
ECOGRACE Cartridge Filter Features:
(1)Air Intake Cartridges for gas turbines and Air compressors are modern and Reliable.
(2)The variety and range of filter materials and specifications make it possible to find suitable filter media for any working conditions.
(3)The quality of the filter material ensure high performance standards.
Specification:
Gas Turbine filter cartridge :
Production description:
Filter Cartridge Product Descriptions:
ECOGRACE Gas Turbine Air Intake Filter cartridges are modern and reliable for air intake applications. They ensure high efficient filtration of dust and other contaminants even in the most polluted environments. Normally these are made of mixture of polyester & cellulose and Nanofiber filter media. The filter media have much better pleat ability & dimensional stability. Pleated filter media offer high filtration efficiency, very fine retention level, easy clean ability & aesthetically good product than other normal filter media.
The filter media is point bonded polyester with even fiber distribution which results in an even dirt load and increased water flow.
The Sharp & Uniform pleated media provides filtration area (square footage) that meets or exceeds the original manufacturers' specifications.
An open core design provides sturdy support for the media without restricting flow. Increased flow rates result in less wear on the pump and reduced energy usage.
Anti-microbial end caps inhibit the growth of bacteria, mold and mildew while supporting the core and media.
Banded Pleats maximize flow during operation, and help to reduce the frequency of cleaning. Banded pleats also make the cartridge easier to clean.
Industrial Dust Collection Cartridge Filter Features:
A:Compact design, reliable performance.
B:Low energy consumption, highest filter efficiency and low cost.
1.Top Cap
Open steel plate, no rust
2.End Cap:
Open or closed steel plate,no rust
3.Filter Surface:
Various available
4.Inner Core;
Galvanized mesh
5.Outer strip band:
Two pieces as reinforcement
6.Gasket:
Seamless neoprene foam
Filters surface-load particulate for easier pulse cleaning
Lower pressure drops (initially and life-long)
Superior releasing abilities reduce cleaning cycles
Reduced energy costs and compressed air savings
Cleaner Air (Lower Emissions)
Longer Filter Life (Fewer Cleanings/Stress)
Reduced Downtime (Fewer Filter Swaps)
Lower Disposal Costs (Fewer Filter Swaps)
Filter Cartridge Product Descriptions:
ECOGRACE Gas Turbine Air Intake Filter cartridges are modern and reliable for air intake applications. They ensure high efficient filtration of dust and other contaminants even in the most polluted environments. Normally these are made of mixture of polyester & cellulose and Nanofiber filter media. The filter media have much better pleat ability & dimensional stability. Pleated filter media offer high filtration efficiency, very fine retention level, easy clean ability & aesthetically good product than other normal filter media.
ECOGRACE Cartridge Filter Features:
(1)Air Intake Cartridges for gas turbines and Air compressors are modern and Reliable.
(2)The variety and range of filter materials and specifications make it possible to find suitable filter media for any working conditions.
(3)The quality of the filter material ensure high performance standards.
Specification:
Model | Shape | O.D(mm) | I.D(mm) | Length(mm) | Filter area(m2) |
ECF-01 | cylinder | 324 | 213 | 559(22") | 18 |
ECF-02 | cylinder | 324 | 213 | 660(26") | 21 |
ECF-03 | cylinder | 324 | 213 | 700(27.5") | 22.3 |
ECF-04 | cylinder | 324 | 213 | 735(29") | 23.5 |
ECF-05a | cylinder | 408 | 293 | 875(34.5") | 33.2 |
ECF-05b | cylinder | 408 | 293 | 559(22") | 21.6 |
ECF-06(twist lock) | cylinder | 324 | 213 | 865(34") | 25 |
ECF-01 | cone | 445-324 | 330-213 | 660(26") | 23.3 |
ECF-02 | cone | 324-250 | 213-134 | 660(26") | 16.4 |
ECF-03 | cone | 408-324 | 293-213 | 711(28") | 23 |
ECF-04(twist lock) | cone | 408-324 | 293-213 | 925(36.6") | 34.3 |
ECF-01(TenKay type) | cylinder | 324Top cap size:406362 | 213 | 668(26.3") | 22 |
ECF-02(TenKay type) | cylinder | 324Top cap size:406362 | 213 | 875(34.5") | 28 |
Gas Turbine filter cartridge :
Model No. | Type | Top Cap ODiameter (mm ) | Cap inside Daimeter ( mm ) | Height (mm ) | Filtration area (m2) |
ECG32R | cylinder | 324 | 213 | 735(29") | 23.5 |
ECG408F | cylinder | 408 | 293 | 875(34.5") | 33.2 |
ECG408F | cylinder | 408 | 293 | 559(22") | 21.6 |
ECG32R | cylinder | 324 | 213 | 865(34") | 25 |
ECG32T | cone | 445-324 | 330-213 | 660(26") | 23.3 |
ECG32T | cone | 324-250 | 213-134 | 660(26") | 16.4 |
ECG408F | cone | 408-324 | 293-213 | 711(28") | 23 |
(twist lock) | cone | 408-324 | 293-213 | 925(36.6") | 34.3 |
(TenKay type) | cylinder | 324 Top cap size406×362 | 213 | 668(26.3") | 22 |
(TenKay type) | cylinder | 324 Top cap size406×362 | 213 | 875(34.5") | 28 |
ECG32R | cylinder | 324 | 213 | 700(27.5") | 22.3 |
