Economic version 2021 Ksj-2.2s industrial air purifier smoke remover smoke remover

 Technical parameters2020 Economic Edition KSJ-2.2S  Industrial Air Purifier Fume Extractor Smoke Eliminator No.ItemParameter1fan typecentrifugal fan2treatment of air flow2000±100 m3/h3motor power2.2 kW4power supply3x220V /60Hz or 3x380V /50Hz5filtration area30 m26number of filter cartridges1 piece7fil

Featured Products

2020 Economic Edition Ksj-2.2s Industrial Air Purifier Fume Extractor Smoke Eliminator


Technical parameters
2020 Economic Edition KSJ-2.2S  Industrial Air Purifier Fume Extractor Smoke Eliminator

No.ItemParameter
1fan typecentrifugal fan
2treatment of air flow2000±100 m3/h
3motor power2.2 kW
4power supply3x220V /60Hz or 3x380V /50Hz
5filtration area30 m2
6number of filter cartridges1 piece
7filter mediumNanomater Fiber or Synthetic wood pulp fiber
8filtration efficiency>99.9%
9noise74±5dB(A)
10Maximum Pressure2200Pa
11Suction arms Ø160mm*3m (2Pcs)
12Weight (excluding suction arm)135±5KG
13Dimensions(excluding suction arm)640×760×1320mm

Product introduction

Incorporated world leading environmental technology, economical mobile fume extractor is a technically advanced industrial dust & fume extractor, it's developed with full consideration of the forming, characteristics and harm of fumes and based on actual conditions of cutting and welding workshop. This product adopted world leading imported material of wood fiber filtering, for dust (above 0.5μm) filtration efficiency reaches 99.9%, meanwhile maintain a high air flow. It is ideal for purifying dry, oil-free, non-corrosive fume mixture generated in cutting and welding, collecting rare metals and valuable materials. Compared with the same product in the world, it's quite worthwhile in terms of quality and price.

2020 Economic Edition Ksj-2.2s Industrial Air Purifier Fume Extractor Smoke Eliminator

Main features

1. Flexible suction arm can rotate 360°and the freedom to stay anywhere

2. Imported material of wood fiber filtering, for dust (above 0.5μm) filtration efficiency reaches 99.9%

3. Depending on needs, 2m, 3m flexible suction arm are available.


2020 Economic Edition Ksj-2.2s Industrial Air Purifier Fume Extractor Smoke Eliminator

Working Principle

Dust laden fume is sucked into the machine through suction hood and suction pipe, hitting on the deflector at the extractor's entrance, slowed and diverted, forming a downward moving air stream, big particles fall into dust collector, which avoid hitting and damaging the filter cartridge, dust filtered out on the filter cartridge's layer surface under the fan's suction force, filtered clean air is directly discharged through the vent into workshop. After each period's use, the filter cartridge should be taken out and use compressed air to blow it from the interior.


Cases

2020 Economic Edition Ksj-2.2s Industrial Air Purifier Fume Extractor Smoke Eliminator
2020 Economic Edition Ksj-2.2s Industrial Air Purifier Fume Extractor Smoke Eliminator





Company profile

2020 Economic Edition Ksj-2.2s Industrial Air Purifier Fume Extractor Smoke Eliminator



Exhibition
2020 Economic Edition Ksj-2.2s Industrial Air Purifier Fume Extractor Smoke Eliminator
